Black Corporation XERXES MK2

XERXES delivers an unmatchable level of warmth through its two digitally controlled analog oscillators. A multimode analog filter, white and pink noise generator, 2 ADSR envelopes, 2 sync-able LFOs, unique analog BBD chorus with 3 modes, full MPE-based polyphonic aftertouch, and complete MIDI control including polyphonic aftertouch and MPE work together to bring a classic analog sound ready to integrate into modern times. MK2 features an updated VCA section, and balanced outputs.

Xerxes produces triangle, saw, square, and PWM waveforms with variable drift controls from each oscillator, sync with variable phase shifting, and ring modulation allowing for complex cross-modulation effects. Each oscillator features an octave switch, bipolar transpose potentiometer +/-7 semitones, a master tuning pot affecting both oscillators, and a detune knob for subtly detuning Oscillator 2 to Oscillator 1. Portamento/Glissando or Glide can be programmed to affect Oscillator 1, 2, or both.

The analog multimode filter on XERXES offers 24db/oct low pass, 12db/oct high pass modes and a band pass filter mode switchable between 6db/oct & 12db/oct for all kinds of filter characteristics. The filter can also be modulated by the dedicated ADSR envelope, LFO, velocity, and aftertouch (MPE and Polyphonic Aftertouch) allowing for incredibly expressive performance and programming.

XERXES features 6 LFO waveforms: Sine, triangle, saw, ramp, square, and random, plus a dedicated delay control to fade the LFO to the full amount set by the depth knob. Two LFOs are selectable with an A/B switch, each of which can be used to control multiple parameters set by the button switches to control oscillator tuning (A/B/Both) filter cutoff, and amplifier levels (VCF/VCA/Both.) Each of these LFOs also includes a Sync on/off switch.

XERXES features a beautiful, fully-analogue BBD-based chorus with 3 selectable modes, similar to the chorus effect found on the vintage Elka Synthex synthesizer. XERXES MK2 is equipped with stereo 1/4”  balanced outputs to take full advantage of the stereo chorusing effect.

Finally, XERXES features full MIDI control and ability to store 128 user presets per bank across 11 banks (Factory, Vintage and 9 user banks) integrating this classic synth concept seamlessly into any studio setup.

•  8-voice polyphonic analogue synthesizer
• 2 discrete logic DCOs per voice
• analogue HP/BP/LP filter
• 2 LFOs
• 2 ADSRs
• polyphonic velocity and aftertouch
• full MPE (midi polyphonic expression) support
• analogue BBD stereo chorus
• 4U rack size with detachable rack ears and wood side panels
• 10 preset banks (x128)
